The Cisco Unified IP Phone 7906G is designed to grow with your organization. A dynamic, soft key-activated feature set helps enable the phone to keep pace with your requirements through regular software upgrades. Moves, adds, and changes are easy; users can simply pick up their phones and move to a new location anywhere on the network. The Cisco Unified IP Phone 7906G also provides accessibility features to those with special needs. Tables 1-7 present the features, specifications, and compliance information of the Cisco Unified IP Phone 7906G, Table 8 provides ordering information, and Table 9 lists available optional accessories.
Table 1. Features and Their Descriptions
|
Feature
|
Description
|
|
Lighted Hold Key
|
Lights when pressed to put a call on hold and stays lit until the held call has been resumed, or flashes if one call is held while another is engaged; is dark when no calls are on hold
|
|
Lighted Menu Key
|
Lights when pressed to access voicemail messages, call logs, network settings, user preferences, corporate directories, and XML services; stays lit while menu items are active
|
|
Lighted Message Waiting Indicator
|
Lights when there is new voicemail and is visible on both the phone chassis and the handset; stays lit until new voicemail has been processed by the user
|
|
Graphical Display
|
Graphical monochrome display with resolution of 192 x 64 pixels provides a scrollable 3-line intuitive access to calling features and text-based XML applications; the Cisco Unified IP Phone 7906G also supports audio-based XML applications
|
|
Four Soft-Key Buttons and a Scroll Toggle Bar
|
Dynamically presents calling options to the user; the scroll toggle bar allows easy movement through the displayed information
|
|
Network Features
|
Offers Cisco Discovery Protocol; IEEE 802.1 p/q tagging and switching
|
|
Volume Control
|
A volume-control toggle provides easy decibel-level adjustments of the handset, speaker, and ringer
|
|
Single-Position Foot Stand
|
Provides optimum display viewing and comfortable use of buttons and keys; the foot stand can be removed for wall mounting with mounting holes located on the base of the phone
|
|
Multiple Ring Tones
|
Offers more than 24 user-adjustable ring tones
|
|
American Disabilities Act (ADA) Features
|
Hearing-aid-compatible (HAC) handset meets the requirements set by the ADA; it also meets ADA HAC requirements for a magnetic coupling to approved hearing aids; the phone dialing pad also complies with the ADA
|
|
Signaling Protocol Support
|
Supported in Cisco Unified CallManager Versions 3.3(5)SR2, 4.1(3)SR3a, 4.2(1)SR1, and higher using Skinny Client Control Protocol (SCCP); supports both SCCP and Session Initiation Protocol (SIP) with Cisco Unified CallManager Version 5.0(2) and higher
|
|
Codec Support
|
Provides G.711a, G.711?, G.729a, and G.729ab and iLBC audio-compression codecs
|
|
Configuration Options
|
Provides provisioning of network parameters through Dynamic Host Configuration Protocol (DHCP)
|
|
Voice Quality
|
Offers comfort-noise generation and voice-activity-detection (VAD) programming on a system basis
|
Table 2. Security Features
|
Item
|
Description
|
|
Certificates
|
Phones are shipped with factory-installed X.509v3 certificates. There is also an option of installing and removing certificates at the customer's site.
|
|
Device Authentication and Signaling Encryption
|
Transport layer security (TLS) with Advanced Encryption Standard (AES)-128 encryption is offered when using Cisco CallManager Version 4.1 or later.
|
|
Media Encryption
|
Secure Real-Time Transport Protocol (SRTP) with AES-128 encryption is offered when using Cisco CallManager Version 4.1 or later.
|
Table 3. Software and Physical Specifications
|
Item
|
Description
|
|
Firmware Upgrades
|
Download firmware changes from Cisco.com
|
|
Software Upgrades
|
Software upgrade supported using a Trivial File Transfer Protocol (TFTP) server
|
|
Dimensions (H x W x D)
|
6.5 x 7 x 6 in. (20.3 x 17.67 x 15.2 cm)
|
|
Weight
|
1.9 lb (0.9 kg)
|
|
Phone Casing Composition
|
Polycarbonate acrylonitrile butadiene styerene (ABS) plastic in textured dark gray with silver-colored bezel
|
Table 4. Power Options
|
Item
|
Description
|
|
Cisco Inline Power
|
Works with Cisco inline power from any Cisco inline power-capable switch
|
|
IEEE 802.3af PoE
|
Works with IEEE 802.3af PoE-compliant blades
|
|
Local Power
|
Can also be powered locally with a power adapter (part number CP-PWR-CUBE-3=) along with one of the power cords listed
|
